New Qubino Flush 1 Relay
The Qubino Flush 1 Relay is a single channel Z-Wave switch capable of controlling lights and appliances up to 10A. It fits into an existing light switch enabling you to wirelessly control appliances as well as measuring their power consumption.
On/Off Flush Relay Switch
Single relay switch capable of operating a load of up to 10A.
- Requires 3-wire (including neutral) installation - further information is in our 2-wire/3-wire guide
- Works with AC or DC power supply (110-230V AC or 24-30V DC)
- Extra switch inputs for controlling additional associated devices or 2-way installations (see note)
The Qubino Flush 1 Relay includes extra features to make it even more useful in your home automation system.
The Relay monitors the power being used by your appliance and reports actual power (Watts) and total consumption (kWh) - helping you control and reduce your energy bills.
Using an optional temperature sensor, the Qubino Relay can report the temperature to your system - you can use this to control heating, blinds and ventilation systems.
Binary Switch and Sensor Input
The Relay can be used with up to three external switches enabling it to control other Z-Wave devices by Association or Trigger Scenes in the main controller.
- Wireless: Z-Wave (868.42MHz)
- Voltage: 110 - 240V, 50Hz or 24 - 30V DC
- Load: 2300W (10A resistive @ 230V AC), 240W (10A resistive @ 24V DC)
- Contacts: Single relay contact
- Power Accuracy: ±3W (@ < 50W), ±3% (@ > 50W)
- Power Consumption: < 0.7W
- Operating Temperature: -10 to +40°C
- Range: up to 50m (outdoors) and 30m (indoors)
- Dimensions (LxWxH): 42 x 37 x 16mm
